HYPR
Series
We strive to make all our business activities green and environmentally friendly. While ensuring greater comfort, safety, energy savings & original designs, our tailor-made elevators offer a new dimension of response to diverse application demands in the market.
Always Responding To The Needs Of The Next Generation Mid-to-High Speed Elevators by HYPR Series
The source of our evolutionary developments is the voice of the era. Quickly revealing and understanding urban needs, our high-speed elevators are continuously evolving.
The Mid-to-High Speed Elevators sets the next stage for elevator design and functionality.
Machine Room
900 -1800 kg
LOAD
3.0-5.0 m/s
SPEED
60
Maximum Number Of Stops
230 m
Maximum Lifting Height
Number of Floors
≤
Rated Speed
≤ 2.5 m/s
Lifting Height
≤ m
Capacity
≤ 3000 kg
Number of Floors
≤
Rated Speed
≤ 4.0 m/s
Lifting Height
≤ m
Capacity
≤ 2000 kg
Products You Can Trust
The Mid-to-High Speed Elevators is proud of the design standards it incorporates to ensure product quality.
Stringent design criteria are applied throughout, from traction machines & speed governors to safety & door devices that interact closely with the user.
Superior quality, realized through strict inspections and quality testing, ensures advanced safety and reliability.
Reliability & Ecology
Uncompromised Reliability
The majority of elevator accidents occur near the doors. That is why we design the area so that breakdowns and the entrapment of passengers are unlikely to happen; and even if they do, the impact of such occurrences is kept to a minimum.
As a result, you can expect the number of callbacks, the burden of restoration work, and the negative impact from interrupted service to be significantly reduced. Everyone can look forward to a safe and trouble-free ride.
Sustainable Performance
With the passage of time, elevator performance can become degraded, leading to slight vibration, operating noise or inaccurate landing. Our elevators are built with high standards of quality.
Using Energy Wisely
Our long-term commitment to developing energy-efficient elevators has created systems and functions that make intelligent use of power.
Yi2- 01
●Car Wall
Hairline stainless steel
●Rear wall
Hairline stainless steel
●Left wall
Hairline stainless steel
●Right wall
Hairline stainless steel
●Ceiling
Surrounding square
●Floor
lmitation rock board PVC
Yi2- 02
●Front wall
Hairline stainless steel
●Rear wall
Middle board: Wood grain steel plate
Auxiliary board: Mirror stainless steel
●Left wall
Middle board: Wood grain steel plate
Auxiliary board: Mirror stainless steel
●Right wall
Middle board: Wood grain steel plate
Auxiliary board: Mirror stainless steel
●Ceiling
Surrounding square
●Floor
lmitation rock board PVC
Safety & Comfort
Considering that elevators are part of society’s infrastructure, their safety & comfort are vital. The Mid-to-High Speed Elevators is packed with functions and considerations to ensure an anxiety-free ride.
Smooth Door Operation
Smooth and quiet door operation has been achieved using a highly efficient Reduced Instruction Set Computer and Variable Voltage, Variable Frequency (VVVF) inverters.
Safe Boarding
Our primary concern is for users to safely step across the threshold. Equipped with an infrared sensor and a retractable safety door edge, the doors stop closing immediately and reopen if a passenger or object is detected.
Comfortable Ride
Leading-edge control systems and devices, along with highly skilled installation technology, assure that even when traveling at high speeds, the ride will be smooth and quiet from start to stop.
Safe & Quick
Emergency Evacuation
The Occupant Evacuation Operation (OEO) enables safe and quick evacuation of occupants from multi-floor buildings at the time of an emergency, such as a fire, by shuttle operation between the evacuation block and the discharge level.
Achieving Optimum Speed, Safety & Comfort
PERMANENT MAGNET TRACTION MACHINE
Thanks to the implementation of our proprietary technologies, such as unique joint-lapped cores built into the motor, we have created a high-performance traction machine with a reputation for comfortable & reliable operation.
SAFETY
The brake system incorporated in the traction machine employs a double-brake configuration to stop the elevator securely.
Additionally, a high-resolution motor encoder maintains superb landing precision for safe boarding and maximum passenger comfort.
SAFETY
Through our ingenious motor design, torque ripple is reduced and a quiet, smooth ride is assured.
Our traction machine also features one of the quietest brakes as a result of advanced noise-reduction technology, which enables changes in electrical current to be detected during brake operation.
STREAMLINED DESIGN
While delivering very powerful output, our traction machines are quite compact due to the high-density winding technology.
HIGH EFFICIENCY
The highest level of efficiency and power factor for traction machines The highest level of efficiency and power factor for traction machines have been achieved via high-density, high-precision winding of the joint-lapped cores.
An intense magnetic field produced around the cores reduces the use of energy, & thereby CO2 emissions.
